Super Seeder

USP of Series :

Super Seeder is a tractor-operated implement offering a one-pass solution for sowing, stubble cutting, and soil preparation. It combines a Rotary Tiller and Seed Planter, mainly used for sowing wheat, soybeans, and other crops like maize, cotton, and sugarcane.

Applications:

• Effective in removing stubble and stopping crop residue burning.
• Saves time and cost by combining multiple field operations in a single pass.
• Enhances soil aeration, water retention, and promotes faster decomposition of crop residues, enriching the soil.
• Enables immediate sowing of wheat after harvesting paddy, reducing downtime between crops.
• Improves seed placement for better germination and results in higher yields compared to traditional methods.
• The machine is also adaptable for tillage and serves as a rotary tiller based on seasonal needs.
• Significant cost savings for farmers on initial investment and crop production by combining plowing and rotavator functions.

Super Seeder Features:

• Roller Drive from Upper Jack Shaft: The front roller drive, provided from the upper jack shaft, minimizes straw choking issues and ensures smooth operation.
• Safety Covers: All moving parts are equipped with safety covers to protect operators and prevent accidental injuries.
• Gearbox Overload Protection: The Super Seeder features a shear bolt or slip clutch for gearbox overload protection, enhancing safety and durability.
• Shifter Unit: The sector-type shifter mechanism ensures precise seed and fertilizer flow control, allowing accurate adjustment of application rates.
• Application Rate Measurement: The machine includes a provision for a scale and handle to measure application rates per acre and adjust settings easily.
• Strong Frame Assembly: The uniquely designed robust and heavy-duty frame provides increased stability, extended machine life, reduced maintenance needs, and superior performance.
• Seed & Fertilizer Tubes: Transparent tubes allow farmers to monitor the flow of seeds and fertilizer, ensuring consistent application.
• Working Width: The Super Seeder offers a working width ranging from 83″ depending on the model. It is equipped with JF type blades for effective seedbed preparation.
• Depth wheel: The sowing depth can be adjusted by depth wheel.
• Gearbox & Roller: It has a heavy duty multi-speed gearbox with gear-driven side transmission and an aluminum fluted roller for seed and fertilizer distribution.
• Metering Device: The Super Seeder has a user-friendly metering system for independent seed and fertilizer adjustments, minimizing waste and improving germination. It’s made of durable aluminum and cast iron for reliable performance.
• Disc & Furrow: The seeder features a high-grade stainless steel disc-type furrow opener with 16.5-inch boron steel discs and is available with 11 tines, both disc and shovel types.
• Blades: Cutter blades shred residue, and forged tynes create furrows on a clean seedbed. The helical JLF blades ensure efficient tillage, better fuel efficiency, and thorough soil mixing.
